Product Specifications
Frame Material: 16 ga (1.6 mm) Galvanneal steel up to and including 30” x 48”. Larger sizes in either dimension are 14 ga (2 mm) Frame Depth: 3-1/4″ (83 mm)
Flange: 7/8” (22 mm) wide up to and including 36” x 36” (914mm x 914mm) or 1-1/4″ (32 mm) wide for larger panels
Door Panel Material: 18 ga (1.31 mm) Galvanneal steel
Liner Material: 22 ga (.64mm) Galvanneal steel
Standard Finish: Off-white prime coat
Insulation: High-temperature insulation
Hinge: Concealed rod hinge up to 48″ (1219 mm) height. Piano hinge for larger sizes
Closer: Panel automatically closes and latches from an open position of approximately 90° as required by NFPA 80
Latch: 1/4″ (6.35mm) Allen key operated slam latch with interior release
CERTIFICATIONS:
Intertek Warnock Hersey Listed and Labeled:
3 Hour fire rating for vertical and horizontal installation.
Temperature Rise Max: 30 minutes 77° F (43° C), 60 minutes 268° F (149° C)
Testing Standards:
Vertical: NFPA 252, UL 10B, CAN/ULC S10 4
Horizontal: UBC 43-7
