Product Specifications
Door & Trim Construction: Cold-rolled steel with white powder-coated finish standard. Flush cabinet doors with a 5/8” door stop are attached by a continuous hinge and equipped with zinc-plated handle and roller catch. All models have 1-3/4” wide trim on frame and 1-1/4″ trim on doors with glazing.
Trim Style & Depth: Recessed Flat 3/8”, Semi Recessed – 1-1/4”, 1-1/2” Square Edge or 2-1/2”, 3”, 4”, 4-1/2” Rolled edge (4” has flush pull). Surface-mount models have a square edge as a standard. Rolled edge surface mount or trimless recessed also available.
Tub: The tub is constructed of steel with white powder-coat finish.
Options: Fire-rated, glazing, pulls, paint colors, alarms.
Listings and Ratings: UL listed and labeled as an approved membrane penetration firestop system for up to 2 hours in accordance with UL 1479 (ASTM-E814) and CAN/ULC-S115.
Note: Not all sizes and options are listed, or available for all models, see submittal for details.
